Browse our ample assortment of UV ballasts for Air & Water Purification. Don’t see it? Ask for it.
NLT’s standard offerings revolve around the comprehensive lighting needs associated with UV Air and Water Purification. This was NLT’s developed area of deep expertise prior to the pandemic and continues to be an area in which we thrive today. Please click the links below for spec sheets (or here for our UV Lamp/Ballast Guide):
• Line Voltage: 120-277V 50/60Hz
• For use with 425 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 800 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 800 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 160 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120VAC, 60Hz
• For use with 425 mA UV Lamps
• Residential Applications
• Lamp End of Life Protection
• Line Voltage: 230VAC, 50/60 Hz
• For use with 425 mA UV Lamps
• Residential Applications
• Lamp End of Life Protection
• Input Voltage: 48VDC Application
• For use with 425 mA UV Lamps
• UV Lamp Monitor by LED Indicator
• Lamp End of Life Protection
• Input Voltage: 24VAC or 24VDC
• For use with 425 mA UV Lamps
• UV Lamp Monitor by LED Indicator
• For Use in Air Conditioning Equipment
• Step down from 240/208/120v to 24VAC
• Suitable for use with NLT114-PH-24V Ballast
• For Use in Air Conditioning Equipment
• Line Voltage: 120-277V 50/60Hz
• For use with 800 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 1000 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 1000 mA UV Lamps
• Capable of monitoring UV Lamp by external LED
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 425 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 8 mA UV Lamps
• Cold Cathode UV Lamp Applications
• Instant Start
• For use with 42″ to 61″ T5 UV Lamps, 400 mA
• For use with 425 mA UV Lamps
• Line Voltage: 120-277V 50/60Hz
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• For use with 16″ to 36″ T5 UV Lamps, 400 mA
• Line Voltage: 120-277V 50/60Hz
• For use with 425 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• For use with 24″ to 42″ T5 UV Lamps, 800 mA
• Line Voltage: 120-277V 50/60Hz
• For use with 800 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• For use with 42″ to 61″ T5 UV Lamps, 800 mA
• Line Voltage: 120-277V 50/60Hz
• For use with 800 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 260 mA UV Lamps
• Series Lamp Operation
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 425 mA UV Lamps
• Series Lamp Operation
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Line Voltage: 120-277V 50/60Hz
• For use with 425 mA UV Lamps
• Parallel Lamp Operation
• Instant Start
• Active Power Factor Correction
• Line Voltage: 108-264V 50/60Hz
• For Air & Water purification applications
• Lamp End of Life Protection
• 0-10V Dimming offers smooth dimming from 50% - 100%
• Short circuit and open load protection
• Remote Enable/Disable Function to turn power ON/OFF
• For use with 42″ to 61″ T5 UV Lamps, 800 mA
• Line Voltage: 120-277V 50/60Hz
• Push-in connectors
• For use with 800 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• For use with 800 mA UV Lamps
• Approved for 1 (60~95W ) T5 UV
• Approved for 1 OR 2 (21W-48W) T5 UV
• Line Voltage: 120-277V 50/60Hz
• Push-in connectors
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Approved for 1 Lamp 60~80W-T5
• Approved for 1 or 2 (41W) -T5
• Approved for 2 Lamp 21W-T5
• Line Voltage: 120-277V 50/60Hz
• Push-in Connectors
• For use with 400 mA UV Lamps
• Lamp End of Life Protection
• Program Start
• Active Power Factor Correction
• Type CC
• Approved for one GPH247T5L(10"), GPH303T5(12"), GPH436T5(17"), PLL18W, PLL36W or TUV 36W/G36T8 lamp
• Line Voltage: 24VDC (20-30VDC)
• Program Start
• UL/cUL, Class “P”, Type 1 Outdoor, Type “CC”, RoHS
Approved for UV lamps: 1 or 2 Lamp (28W) GPH212T5HO; 1 Lamp (28W~58W) GPH212T5HO, GPH357T5HO, or GPH645T5HO
Line Voltage: 24VDC (20-30VDC)
Program Start
UL/cUL, Class “P”, Type 1 Outdoor, CE, RoHS
• Approved for 2 T12 Lamps - 160W
• Line Voltage: 220-240V
• Instant Start
• CE
• Approved for 2 T12 Lamps - 200W
• Line Voltage: 220-240V
• Instant Start
• CE
• Approved for 2 or 3 T12 Lamps - 100 or 120W
• Line Voltage: 220-240V
• Instant Start
• CE
• Approved for 2 T12 Lamps - 180W
• Line Voltage: 220-240V
• Instant Start
• CE
Approved for 2 T12 Lamps - 200W
Line Voltage: 220-240V
Instant Start
CE
